MSI PRO DP10 13M - Barebone Mini Desktop Computer

MSI PRO DP10 13M Mini Desktop Computer (Barebone)

The MSI PRO DP10 13M Mini Desktop is a barebone mini PC designed for users who need a compact, customizable, and highly productive computing solution. With a 13th Gen Intel Core i5 processor, Intel Iris Xe Graphics, and plenty of expansion options, this mini desktop is ideal for home offices, small businesses, education, hospitality, or science applications. Its versatile design, support for multiple displays, and high-speed connectivity options make it a powerful addition to any workspace.

Key Features & Benefits

1. Powerful 13th Gen Intel Core i5-1340P Processor

• 12-Core Design: Powered by the Intel Core i5-1340P processor, this mini desktop features 12 cores—8 Performance cores running at a base clock of 1.9 GHz (boosting up to 4.6 GHz) and 4 Efficiency cores designed to handle background tasks. This architecture provides a balanced mix of power and energy efficiency, making it ideal for multitasking and handling both work-related applications and lighter entertainment or productivity tasks.
• Multi-Core Performance: With 12 cores in total, the i5-1340P offers excellent performance for everyday office tasks, multitasking, browsing, and running productivity software. The Intel Turbo Boost Technology ensures demanding tasks get the performance they need without sacrificing energy efficiency.

2. Customizable Memory and Storage Options

• Up to 64GB DDR4 RAM: The MSI PRO DP10 13M supports up to 64GB of DDR4 RAM running at 3200 MHz, which is perfect for users who need to handle large files, complex data, or multitask between many applications. The memory is customizable, giving you the flexibility to configure it based on your needs.
• Expandable Storage: With support for two M.2 PCIe SSD slots and a 2.5" drive bay, the mini desktop allows for quick storage expansion. You can install high-speed PCIe SSDs for fast data access or add traditional hard drives for larger storage capacities. The system is OS-ready, so you can easily install your preferred operating system.

3. Integrated Intel Iris Xe Graphics

• The Intel Iris Xe Graphics are perfect for standard office work, multimedia playback, and light creative tasks like image editing or graphic design. Although this is not a high-end gaming PC, the Iris Xe will support up to two 4K monitors via the Thunderbolt 4 port, ensuring good visual quality for presentations, videos, and other high-resolution displays.

4. Multi-Display Support

• The MSI PRO DP10 13M mini desktop is built for multi-display setups, supporting up to three monitors simultaneously via DisplayPort, HDMI, and VGA. This makes it ideal for users who need to have multiple applications open at once or those working with large datasets or media content.
• Thunderbolt 4 Port: For the ultimate multi-monitor experience, the Thunderbolt 4 port supports up to two 4K monitors or one 8K display, offering unparalleled display flexibility. Whether you're presenting, creating, or working across several tasks, this mini PC will deliver crisp and high-quality visuals.

5. High-Speed Connectivity

• Thunderbolt 4: With a maximum data transfer rate of 40 Gb/s, Thunderbolt 4 offers lightning-fast connectivity for external devices such as high-speed storage drives, 4K/8K displays, or docking stations. You can also daisy-chain up to six devices from a single port.
• USB 3.2 Gen 1 & 2: There are multiple USB 3.2 ports on both the front and rear panels for connecting peripherals such as a keyboard, mouse, external storage, and more. The USB 3.2 Gen 2 port offers speeds of up to 10 Gb/s, while the USB 3.2 Gen 1 ports offer 5 Gb/s transfer rates.
• 2.5G Ethernet Port & Wi-Fi 6E: For wired connectivity, the 2.5G Ethernet port ensures fast, reliable network speeds, ideal for video conferencing, file sharing, or any high-bandwidth applications. The system also supports Wi-Fi 6E (802.11ax) for faster wireless speeds, greater range, and less interference, making it perfect for homes and offices with multiple devices.

6. Compact & Versatile Design

• The MSI PRO DP10 13M features a compact form factor with a VESA mount that lets you easily mount the mini PC to the back of a compatible monitor or place it under a desk. This design is perfect for spaces where desk real estate is limited and where the PC needs to be out of sight but still accessible.
• The system is versatile enough to be used in home offices, education settings, hospitality, or scientific workstations. Its small size, coupled with the ability to mount it discreetly, makes it ideal for applications that require efficient space management.

7. OS Ready and Easy Setup

• The MSI PRO DP10 13M is OS-ready, which means you can easily install your preferred operating system (e.g., Windows, Linux, etc.) and get to work without waiting for pre-installed software. This allows for greater customization and the ability to work with the operating system that best suits your needs.
• Setting up the system is a breeze, and MSI’s barebone design means you can add your own components, such as RAM, storage, and OS, to fit your specific requirements.

Key Specifications

• Processor: Intel Core i5-1340P (12 Cores: 8 Performance cores, 4 Efficiency cores, up to 4.6 GHz Turbo Boost)
• Graphics: Intel Iris Xe Graphics (integrated)
• Memory: Up to 64GB DDR4 3200 MHz RAM
• Storage:
  • 2 x M.2 PCIe SSD slots
  • 1 x 2.5" drive bay
• Connectivity:
  • 2.5G Ethernet port
  • Wi-Fi 6E (802.11ax)
  • Bluetooth 5.3
  • 1 x Thunderbolt 4 (40 Gb/s)
  • 1 x USB 3.2 Gen 2 (10 Gb/s)
  • 3 x USB 3.2 Gen 1 (5 Gb/s)
  • HDMI, DisplayPort, VGA
  • 3.5mm Audio
• Display: Supports up to 3 monitors (2 x 4K or 1 x 8K via Thunderbolt 4)
• OS: OS-ready (user-installs OS)
• Mounting: VESA mount (75mm x 75mm)
• Size: Compact, barebone design for easy placement and installation

Why Choose the MSI PRO DP10 13M Mini Desktop?

1. Compact & Flexible: Perfect for environments with limited space, this mini desktop offers a sleek, compact design that can be mounted behind a monitor or hidden under a desk using the VESA mount.
2. Expandable & Customizable: The barebone design allows you to add your own memory, storage, and operating system, giving you complete flexibility to build a system that meets your specific needs.
3. High-Speed Performance: With 12 cores from the Intel Core i5-1340P processor, Intel Iris Xe Graphics, and Thunderbolt 4, this PC is ready for multitasking, high-speed data transfer, and multi-display configurations.
4. Future-Proof Connectivity: Enjoy the latest in connectivity with Wi-Fi 6E, 2.5G Ethernet, and Thunderbolt 4—ensuring fast network speeds and easy connections to external devices.
5. Multi-Display Support: Easily manage multiple tasks and boost productivity with up to three displays, including support for 4K and 8K resolutions via Thunderbolt 4.
6. Efficient Performance for Work: Whether you’re in an office, classroom, or science lab, the Intel Core i5 processor and integrated graphics provide an efficient balance of power and energy savings.
